FULL SPECIFICATIONS

Verified Australian-model data shown.
ENGINE
Engine Model
Cummins 6LTAA8.9-C325
Engine Type
High-pressure common rail, turbocharged
Number of Cylinders / Bore x Stroke
6
Emission Standard
Tier 2 / Stage II
Displacement
8.9 L
Power Output
241 kW @ 2,000 rpm
HYDRAULIC SYSTEM
Hydraulic System Type
Variable piston pump
Maximum Hydraulic Flow / Discharge Flow
2 x 300 L/min
DIGGING FORCE
Bucket Digging Force
234 kN
Arm Digging Force
174 kN
BUCKET
Bucket Type
Backhoe bucket
Bucket Capacity
1.6 m³
Bucket Width
1,533 mm
TRAVEL SYSTEM
Travel System Type
Axial variable plunger motor
Track Rollers
9 x 2
Carrier Rollers
2 x 2
Track Shoes
48 x 2
Travel Speed
3.0-5.1 km/h
Maximum Drawbar Pull / Traction Force
283 kN
Gradeability
70% (35°)
REFILL CAPACITY
Fuel Tank Capacity
620 L
Cooling System Capacity
35 L
Engine Oil Capacity
22 L
Hydraulic Oil Tank Capacity
300 L
Hydraulic System Capacity
420 L
OPERATING WEIGHT
Shoe Width
600 mm
Ground Pressure
61.5 kPa
Operating Weight
34,500 kg
DIMENSIONS
Transport Length (Arm Lowered)
Overall Length
11,260 mm
Ground Contact Length (Transport)
6,900 mm
Overall Height (Top of Canopy)
Overall Height (Top of Boom)
3,770 mm
Overall Width
3,200 mm
Overall Height (Top of Cab)
3,210 mm
Undercarriage Width (Retracted)
Undercarriage Width (Extended)
Undercarriage Length
Upper Body Width (Zero Tail)
Counterweight Ground Clearance
1,260 mm
Minimum Ground Clearance
530 mm
Tail Swing Radius
3,520 mm
Tread
4,030 mm
Track Length
4,935 mm
Track Gauge
2,600 mm
Track Width
3,200 mm
Bonnet Height
2,830 mm
Revolving Frame Width
3,190 mm
Swivel Centre to Tail Distance
3,465 mm
WORKING RANGE
Maximum Digging Height
10,030 mm
Maximum Dumping Height
6,890 mm
Maximum Digging Depth
7,070 mm
Maximum Vertical Digging Depth
5,685 mm
Maximum Depth Cut at 2,500 mm Level Bottom
6,880 mm
Maximum Digging Distance
10,840 mm
Maximum Digging Radius at Ground Level
10,645 mm
Minimum Swing Radius of Work Equipment
4,430 mm
Maximum Dozer Lift Height
Maximum Dozer Digging Depth
Maximum Boom Offset (LH)
Maximum Boom Offset (RH)
Boom Swing Angle (LH / RH)
SWING SYSTEM
Swing Motor Type
Swash plate plunger motor
Swing Speed
0-10.5 r/min
Brake Type
Pressure release mechanical braking
