EXCAVATOR

Type your paragraph here

Type your paragraph here


Operating Weight

Type your paragraph here

Bucket capacity

Type your paragraph here

FULL SPECIFICATIONS


Verified Australian-model data shown.
ENGINE
Engine Model
Yanmar 3TNV80F
Engine Type
Three-cylinder direct injection
Number of Cylinders / Bore x Stroke
3
Emission Standard
EPA Tier 4 Final / Europe Stage V
Displacement
1.267 L
Power Output
14.6 kW @ 2,400 rpm
HYDRAULIC SYSTEM
Hydraulic System Type
Axial piston variable displacement
Maximum Hydraulic Flow / Discharge Flow
87 L/min
DIGGING FORCE
Bucket Digging Force
24 kN
Arm Digging Force
14.8 kN
BUCKET
Bucket Type
Backhoe bucket
Bucket Capacity
0.06 m³
Bucket Width
490 mm
TRAVEL SYSTEM
Travel System Type
Axial piston motor
Track Rollers
2 x 3
Carrier Rollers
Track Shoes
2 x 39
Travel Speed
2.4 / 4.2 km/h
Maximum Drawbar Pull / Traction Force
29 kN
Gradeability
58%
REFILL CAPACITY
Fuel Tank Capacity
33 L
Cooling System Capacity
5 L
Engine Oil Capacity
3.4 L
Hydraulic Oil Tank Capacity
22 L
Hydraulic System Capacity
OPERATING WEIGHT
Shoe Width
300 mm
Ground Pressure
26.3 kPa
Operating Weight
2,680 kg
DIMENSIONS
Transport Length (Arm Lowered)
4,200 mm
Overall Length
Ground Contact Length (Transport)
Overall Height (Top of Canopy)
2,480 mm
Overall Height (Top of Boom)
Overall Width
Overall Height (Top of Cab)
Undercarriage Width (Retracted)
Undercarriage Width (Extended)
1,550 mm
Undercarriage Length
2,020 mm
Upper Body Width (Zero Tail)
1,400 mm
Counterweight Ground Clearance
Minimum Ground Clearance
Tail Swing Radius
715 mm
Tread
Track Length
Track Gauge
Track Width
Bonnet Height
Revolving Frame Width
Swivel Centre to Tail Distance
WORKING RANGE
Maximum Digging Height
4,390 mm
Maximum Dumping Height
3,060 mm
Maximum Digging Depth
2,800 mm
Maximum Vertical Digging Depth
2,310 mm
Maximum Depth Cut at 2,500 mm Level Bottom
Maximum Digging Distance
4,800 mm
Maximum Digging Radius at Ground Level
4,680 mm
Minimum Swing Radius of Work Equipment
Maximum Dozer Lift Height
300 mm
Maximum Dozer Digging Depth
320 mm
Maximum Boom Offset (LH)
Maximum Boom Offset (RH)
Boom Swing Angle (LH / RH)
SWING SYSTEM
Swing Motor Type
Cycloidal motor
Swing Speed
0-10 r/min
Brake Type
Pressure release mechanical braking

DOWNLOAD PRODUCT BROCHURE

Keep the current specification sheet available as a direct PDF download.

Built for high-volume material handling


Type your paragraph here

HIGH PERFORMANCE BACKED BY EVCORE SUPPORT

Add Your Heading Text Here

Add Your Heading Text Here

Add Your Heading Text Here

Add Your Heading Text Here

Add Your Heading Text Here

Add Your Heading Text Here

Videos & Walkarounds


Backed by EVCORE’s Australia-wide team of expert technicians, keeping your machines working wherever the job takes you..

What our customers are saying


The L56 performed better than I thought it would. It looked good on paper but it also performs well. Better than I thought. I originally bought it with the Hay Forks and Tiptoe bucket, but then I ended up getting a rake as well. They all get used. The L56 does everything.
The Cummins engine, it's simple and it works! To Evcore you're not just a client, you're a mate. They want to help you. I rate these guys as one of the best service providers of any of my machines.
- Ivan Robertson

Support that keeps you moving


Every Shantui machine is supported by EVCORE's national service network, with trained technicians and locally stocked parts to get your machines working as quickly as possible.

National-Service

NATIONAL
SERVICE

Trained-Technicians

TRAINED
TECHNICIANS

Local-Parts

LOCAL
PARTS

On-Site-Support

ON-SITE
SUPPORT

Attachments


Get more from your machine with robust, versatile attachments designed to expand capability across construction, agriculture and material-handling applications. Hydraulic quick-hitch compatibility enables fast changeovers and helps keep your machine productive. Selected attachments can also be modified to suit other machinery brands.

Attachment-Jib Attachement-stick-rake Attachement-drill-hole-borer Attachement-tip-toe-bucket Attachement-articulated-push-blade Attachement-hay-forks Attachements-stone-bucket Attachement-rippers

Enquire about the SE26 Excavator


For pricing and more information contact the EVCORE team.

Enquire about the SE26 Excavator


For pricing and more information contact the EVCORE team.
