FULL SPECIFICATIONS


Verified Australian-model data shown.
ENGINE
Engine
Cummins QSX15
Emission
US EPA Tier 3, EU Stage IIIA
Rated Revolution
1,800 rpm
Horse Power
510 hp
Gross Power
380 kW
Net Power
343 kW
Number of Cylinders
6 cylinders
Displacement
15 L
Maximum Torque
2,365 Nm @ 1,400 rpm
Minimum Fuel Consumption
Cooling System
Smart temperature-controlled fan
DRIVE SYSTEM
Drive Type
hydrostatic
Drive System
Independent dual-circuit electric control hydrostatic drive with mono-lever travel and steering control
System Overflow Pressure
43,500 kPa
Travel Speed Forward
0-11 km/h
Travel Speed Reverse
0-11 km/h
Maximum Theoretical Traction Force
Torque Converter
Transmission
Central / Bevel Gear Drive
Steering
Independent track drive for pivot steering and steering under load
Steering Clutch
Braking System
Regular closed multi-disk brake
Brake Clutch
Final Drive
Double-reduction spur gear and planetary gear
CHASSIS SYSTEM
Chassis Type
Pivot equalizing beam suspended semi-rigid structure
Track Shoe Type
Single grouser
Track Gauge
2,260 mm
Width of Track Shoe
610 / 660 / 710 mm
Track Grounding Length
3,532 mm
Track Grounding Area
21,545 cm²
Number of Track Shoes
40 pcs per side
Grounding Pressure
120 kPa
Number of Carrier Rollers
2 pcs per side
Number of Track Rollers
7 pcs per side
Track Pitch
260 mm
REFILL CAPACITY
Fuel Capacity
920 L
Coolant Capacity
73 L
Engine Oil Capacity
45-49 L
Hydraulic Oil Tank Capacity
370 L
Hydraulic Work Oil Capacity
43 L per side
Transmission Oil Capacity
Drive Axle Oil Capacity
Final Drive Oil Capacity
Transfer Case Oil Capacity
6 L
OPERATING WEIGHT
Operating Weight Standard
56,000 kg
Operating Weight Traction Frame
Operating Weight Ripper
Operating Weight Winch
Operating Weight Cabin and Traction Frame
Operating Weight Cabin and Draw Bar
Operating Weight Cabin and Ripper
Operating Weight ROPS Canopy and Traction Frame
Operating Weight ROPS Canopy and Ripper
Operating Weight ROPS Shed and Traction Frame
Operating Weight ROPS Shed and Ripper
BLADE
Blade Type
Rock Blade
Blade Capacity
13.7 m³
Maximum Lifting Height of Blade
1,460 mm
Maximum Digging Depth of Blade
660 mm
Blade Digging Angle
53° ±3°
Blade Width
4,320 mm
Blade Height
1,950 mm
Maximum Blade Turning Angle on Ground
Maximum Blade Tilt Height
1,140 mm
DIMENSIONS
Machine Height
3,990 mm
Track Grouser Height
87 mm
Ground Clearance
680 mm
Machine Length With Air Conditioning
Machine Length With Draw Bar
Machine Length Without Draw Bar
Machine Length With Ripper
9,325 mm
Machine Length Without Ripper
7,085 mm
Overall Machine Length
Machine Width at Maximum Blade Angle
Track Shoes Outside Width
Left Track Shoe to Blade Clearance
Right Track Shoe to Blade Clearance
Minimum Turning Radius
RIPPER
Ripper Type
Single shank ripper
Ripper Weight
3,728 kg
Maximum Ripping Depth
1,245 mm
Maximum Ripper Lifting Height
1,056 mm
Ripper Length at Deepest Ripping
2,475 mm
Ripper Length at Highest Position
Ripper Width
1,490 mm
Ripper Tilt Angle at Highest Position
37.5°
Ripping Width
Ripper Tooth Width
Distance Between Ripper Teeth
Ripper Departure Angle
