DH08 BULLDOZER
$8.00
Overall Weight
8,680 kg
Engine Model
WEICHAI WP4G95E221
Engine Power
70 kW (94hp)
DOWNLOAD PRODUCT PDF
CLOSE
DH08 BULLDOZER
Overall Weight
8,680 kg
Engine Model
WEICHAI WP4G95E221
Engine Power
70 kW (94hp)
CLOSE
REQUEST QUOTE
DH08 BULLDOZER
Overall Weight
8,680 kg
Engine Model
WEICHAI WP4G95E221
Engine Power
70 kW (94hp)
Overview of the DH08 Dozer
The Shantui DH08 Dozer is a compact and efficient machine designed for versatile applications in construction, landscaping, and agricultural projects. Equipped with a reliable Weichai WP4 engine, it delivers 70 kW (approximately 94 hp) of gross power at 2200 rpm, ensuring robust performance for various tasks. The DH08 features a hydrostatic drive system with electronic control, offering smooth and precise operation in diverse working conditions. Its compact design, combined with a versatile Power Angle Tilt (PAT) blade, makes it ideal for tasks requiring agility and precision.
Key Features:
-
Reliable Engine: The Weichai WP4 engine provides 70 kW (approximately 94 hp) of gross power at 2200 rpm, ensuring consistent performance across various applications.
-
Hydrostatic Drive System: The electronic control hydrostatic transmission offers stepless speed variation, enhancing maneuverability and operational efficiency.
-
Versatile PAT Blade: Equipped with a Power Angle Tilt blade with a capacity of 1.93 m³, the DH08 allows for flexible earthmoving and grading operations.
Technical Specifications:
-
Engine: Weichai WP4, 70 kW (approximately 94 hp) gross power at 2200 rpm
-
Hydrostatic Drive: Electronic control with stepless speed variation
-
Track Shoe Width: 460 mm
-
Blade Capacity: 1.93 m³
-
Fuel Capacity: 197 L
-
Operating Weight: 9580 kg
-
Machine Dimensions: 4568 mm (length) x 2680 mm (width) x 2950 mm (height)
Why Choose the Shantui DH08 Dozer?
The Shantui DH08 Dozer is engineered for tasks that demand both precision and reliability. With its robust Weichai engine, advanced hydrostatic drive system, and versatile PAT blade, the DH08 is well-suited for a variety of applications, from fine grading to light earthmoving. Its compact size and efficient design make it an excellent choice for projects where maneuverability and precision are paramount.
About Evcore
Evcore is the exclusive dealer for Shantui Construction Machinery in Australia, offering comprehensive parts and service support for all our machines. For more information on the Shantui DH08 Dozer, contact us today.
Phone: 0400 459 097 (SA) | 0409 874 144 (WA)
Email: sales@evcore.com.au
Website: shantuiaustralia.com.au
ENGINE
| Engine | Weichai WP4G95E221 |
| Emission Standard | China-III |
| Rated Speed | 2200 rpm |
| Gross Power | 70 kW / 94 HP |
| Piston Displacement | 4.5 L |
| Maximum Torque | 320 N·m / 1400-1600 rpm |
DRIVE SYSTEM
| Drive System | Independent dual-circuit electronically controlled hydrostatic drive, intelligent matching of load changes |
| System Overflow Pressure | 28,000 kPa |
| Travel Speed – Forward | 0–10 km/h |
| Travel Speed – Reverse | 0–10 km/h |
| Traction Force | 110 kN |
| Steering Clutch | Hydrostatic differential steering, pivot steering, load steering |
| Steering Brake | Normally closed brake |
| Final Drive | Single-stage spur gear reduction + planetary reduction |
CHASSIS SYSTEM
| Type | Pivot shaft suspension, semi-rigid chassis | Pivot shaft suspension, semi-rigid chassis | Pivot shaft suspension, semi-rigid chassis |
| Track Shoe Type | Single Grouser (XL) | Wetland Type (LGP) | Wetland Type – Wider Shoes |
| Track Gauge | 1,260 mm | 1,260 mm | 1,260 mm |
| Track Shoe Width | 390 mm / 460 mm | 690 mm / 760 mm | 860 mm |
| Track Grounding Length | 1,900 mm | 1,900 mm | 1,900 mm |
| Track Grounding Area | 7,410 cm² / 8,740 cm² | 13,110 cm² / 14,440 cm² | 16,340 cm² |
| Number of Track Shoes | 37 pcs/side | 37 pcs/side | 37 pcs/side |
| Ground Pressure (Standard Configuration) | 46.3 kPa / 39.2 kPa | 26.1 kPa / 23.7 kPa | 21.1 kPa |
| Number of Carrier Rollers | 1 pcs/side | 1 pcs/side | 1 pcs/side |
| Number of Track Rollers | 5 pcs/side | 6 pcs/side | 6 pcs/side |
| Pitch | 154 mm | 154 mm | 154 mm |
REFILL CAPACITY
| Fuel capacity | 197 L (52 gal.) |
| Coolant liquid capacity | 19 L (5.0 gal.) |
| Engine oil capacity | 10 L (2.6 gal.) |
| Hydraulic oil tank | 53 L (14 gal.) |
| Final drive | 5.8 L (1.52 gal.)/single side |
OPERATING WEIGHT
| Operating weight (ROPS canopy + traction frame) | XL: 8680 kg (19136 lb.) | LGP: 9090 kg (20044 lb.) |
| Operating weight (ROPS canopy + ripper) | XL: 9350 kg (20591 lb.) | LGP: 9750 kg (21493 lb.) |
| Operating weight (Cabin + traction frame) | XL: 8950 kg (19731 lb.) | LGP: 9360 kg (20640 lb.) |
| Operating weight (Cabin + ripper) | XL: 9600 kg (21164 lb.) | LGP: 10200 kg (22088 lb.) |
BLADE
| Blade type | XL: PAT | LGP: PAT |
| Blade capacity | XL: 1.93 m³ (2.5 cu. yd.) | LGP: 2.04 m³ (2.7 cu. yd.) |
DIMENSIONS
| Machine height (with Track grouser height) | XL: 2950 mm (116 in.) | LGP: 2950 mm (116 in.) |
| Track grouser height | XL: 47 mm (1.9 in.) | LGP: 47 mm (1.9 in.) |
| Ground clearance | XL: 320 mm (13 in.) | LGP: 320 mm (13 in.) |
| Machine length (with air condition) | XL: 4586 mm (180.6 in.) | LGP: 4586 mm (180.6 in.) |
| Machine length (with draw bar) | XL: 4468 mm (176.4 in.) | LGP: 4468 mm (176.4 in.) |
| Machine length (without draw bar) | XL: 4373 mm (153.2 in.) | LGP: 4373 mm (153.2 in.) |
| Length of blade to center of final drive | XL: 3780 mm (148.8 in.) | LGP: 3780 mm (148.8 in.) |
| Length of center of idle wheel final drive | XL: 2225 mm (87.6 in.) | LGP: 2225 mm (87.6 in.) |
| Max. lifting height of blade | XL: 900 mm (35 in.) | LGP: 900 mm (35 in.) |
| Max. digging depth of blade | XL: 450 mm (17.7 in.) | LGP: 450 mm (17.7 in.) |
| Digging angle of blade | XL: 55°±3° (deg.) | LGP: 55°±3° (deg.) |
| Blade width | XL: 2680 mm (106 in.) | LGP: 3150 mm (124 in.) |
| Blade height | XL: 1090 mm (42.9 in.) | LGP: 1090 mm (42.9 in.) |
| Max blade turning angle on ground | XL: 25° (deg.) | LGP: 25° (deg.) |
| Machine width when blade in max turning angle | XL: 2474 mm (97.4 in.) | LGP: 2896 mm (114 in.) |
| Max tilt height of blade | XL: 389 mm (15.1 in.) | LGP: 457 mm (18 in.) |
| Vertical distance from left track shoe outside to blade outside when blade in max turning angle | XL: 1840 mm (0.2 in.) | LGP: 2040 mm (2.5 in.) |
| Track shoes outside width | XL: 2110 mm (83 in.) | LGP: 2400 mm (95 in.) |
| Vertical distance from right track shoe outside to blade outside when blade in max turning angle | XL: 364 mm (14.4 in.) | LGP: 432 mm (17 in.) |
| Min turning radius | XL: 2790 mm (109.8 in.) | LGP: 2800 mm (110.2 in.) |
RIPPER
| Max. ripping depth | XL: 340 mm (13.4 in.) | LGP: 340 mm (13.4 in.) |
| Max. lifting height | XL: 440 mm (17.3 in.) | LGP: 440 mm (17.3 in.) |
| Ripper length (at deepest ripping) | XL: 1366 mm (53.8 in.) | LGP: 1366 mm (53.8 in.) |
| Ripper length (at highest point) | XL: 972 mm (38.3 in.) | LGP: 972 mm (38.3 in.) |
| Ripper width | XL: 1766 mm (69.5 in.) | LGP: 1766 mm (69.5 in.) |
| Ripping width | XL: 1696 mm (66.8 in.) | LGP: 1696 mm (66.8 in.) |
| Distance between ripper teeth | XL: 800 mm (31.5 in.) | LGP: 800 mm (31.5 in.) |
